Geometry Correction Workspace
Working from Model v3Grid: 100mm
3 geometry issues detected
Wall W-1034 (96%)Unconnected Wall EndpointValidation Issues (3)
Wall endpoints not connected
Gap of 140mm detected between Wall W-1034 and W-1035.
Door not associated with wall
Door D-202 does not have a host wall parent element.
Space boundary overlap detected
Minor overlap between Space S-04 and the adjacent corridor boundary.
Selected Element
Wall W-1034
Classification: Load-Bearing Exterior
Element TypeIfcWall
ClassificationLoad-Bearing
Length4,820 mm
Thickness240 mm
Elevation0.00 mm
Confidence96.4%
SourceML Inference Engine
LevelLevel 01
Unsaved changes detected. Last corrected: 2 min ago.
